PRODUCT
鋁合金及玻璃纖維增強塑料;外框鋁合金，扇葉PBT UL94V-0等級
散熱風扇
產品描述
Product Description
SIZE:80x80x25mm
CONSTRUCTION:Die-cast aluminum housingGlass fiber reinforced plastic:Impeller is UL 94V-0 rating Shaded pole motorThermal protected or Impedance protectedLead wire or terminal is available
OPERATING TEMPERATURE:Ball bearing -10℃to +70℃;Sleeve bearing -10℃ to +60℃
INSULATION RESISTANCE:10meg Ohm min, at 500 VDC(between frame and terminal)
DIELECTRIC STRENGTH:1mA max, at 2000 VAC 1minute(between frame and terminal)
尺寸圖
Dimensions Drawing
特征曲線
Characteristic Curves
規格參數
Specifications
| SIZE (mm) | MODEL | Bearing(X) | Voltage | Testing Current | SPEED (RPM) | AIR FLOW (CFM) | PRESSURE (mmAq) | NOISE (dBA) | W (g) |
| 6025G | YDU6025B12G | B | 12 | 1.80 | 13000 | 56.77 | 50.37 | 60.60 | 65 |
| YDD6025B12G | 0.82 | 10000 | 43.36 | 30.39 | 53.50 | 65 | |||
| YDH6025B12G | 0.28 | 7000 | 29.79 | 14.71 | 43.40 | 65 | |||
| YDM6025B12G | 0.10 | 5000 | 21.31 | 7.66 | 34.90 | 65 | |||
| YDL6025B12G | 0.05 | 3500 | 14.67 | 3.76 | 25.30 | 65 | |||
| YDU6025B24G | 24 | 0.90 | 13000 | 56.77 | 50.37 | 60.60 | 65 | ||
| YDD6025B24G | 0.41 | 10000 | 43.36 | 30.39 | 53.50 | 65 | |||
| YDH6025B24G | 0.14 | 7000 | 29.79 | 14.71 | 43.40 | 65 | |||
| YDM6025B24G | 0.05 | 5000 | 21.31 | 7.66 | 34.90 | 65 | |||
| YDL6025B24G | 0.03 | 3500 | 14.67 | 3.76 | 25.30 | 65 |
1.Specifications subject to change without notiec;
2.Design and provide products according to client’s requirements.
